Why CockroachDB and PostgreSQL Are Compatible

CockroachDB is built to be largely compatible with PostgreSQL, meaning that software written to use PostgreSQL can sometimes (often!) be used with CockroachDB without changes.

[Note: MySQL migration and compatibility is currently in development, with experimental functionality available in the latest alpha release.]

Why was CockroachDB designed to be compatible with PostgreSQL?

Perhaps surprisingly, the answer to this question is currently (as of early May 2018) not documented publicly, neither on the CockroachDB web site, nor in the CockroachDB docs, nor in CockroachDB-related articles in third party sources.

I was lucky to sit next to Cockroach Labs CTO and Co-Founder Ben Darnell when Lakshmi Kannan, a product manager, asked us the very same question: Why was CockroachDB designed to be compatible with PostgreSQL? What follows is an extended rewording of the resulting discussion.

Disclaimer: this is a personal recollection written without notes and after a week had passed. Any inaccuracy in the ideas, arguments, timelines, statements, facts or opinions recollected here is entirely mine.

Why is CockroachDB compatible with anything at all?

CockroachDB could very well have been created with its own SQL dialect and/or network protocol. This is the way RethinkDB did it. Although Google’s Spanner’s SQL dialect is inspired by MySQL, it is not fully compatible with it either. Compatibility with anything is a choice, it is not inherently necessary when building a SQL RDBMS. Avoiding compatibility can even be a way to commercial success, by enabling vendor lock-in.

The primary reason to choose compatibility is to make sure our users don’t have to learn too many new things just to use CockroachDB.

When designing a custom network protocol, the database provider must also provide client drivers. Considering the multitude of platform and programming languages in use today, a custom protocol yields a hard choice: either focus on a few platform/language combinations and only provide drivers for that, or divert a lot of engineering resources on client drivers. The former choice yields a smaller potential user base. The latter choice takes resources away from the implementation of a better RDBMS.

By adopting an established network protocol, especially one for which drivers exist on many platforms and for many programming languages, a new RDBMS makes itself immediately available to a larger ecosystem of existing client code.

This is why CockroachDB chose to be compatible with an established RDBMS.

There is one more thing to be said here about multiple layers of compatibility. I will come back to this in a moment.

How does a project like CockroachDB choose what to be compatible with?

There are plenty of well-known and widely used RDBMSs out there. After deciding a new project should be compatible with anything, how does one choose what to be compatible with?

Here, two first-order constraints came into play for CockroachDB.

The first is that CockroachDB was open source from the get-go. It was thus essential to choose compatibility with other RDBMSs that have open source drivers and applications. More specifically, it was legally necessary to choose compatibility with other RDBMSs whose open source drivers are legally allowed to connect to another product than what they were designed for. An open source driver for MSSQL, for example, is no good, because the MSSQL network protocol is likely patent-encumbered and no “MSSQL compatible” database can be built without onerous agreements with Microsoft (if at all). Substitute “MSSQL” with “DB2” or “Oracle” and the argument remains.

The second constraint is that CockroachDB aimed to appeal to open source developers. What do open source developers like? Open source client drivers are one thing, but the ecosystem around the technology matters much more. There must exist welcoming communities, public discussion forums, a free market of third party software, free and open learning resources, etc. In contrast, many proprietary RDBMSs restrict discussion around their tech to semi-private forums. They often have complex third party publishing restrictions. Training to learn and use the technology is usually restricted and expensive.

So for CockroachDB, proprietary RDBMS were out of the compatibility story from the get-go.

What remains? CockroachDB looked at:

  • long-established projects for which the client ecosystem is already mature, again in the interest of reducing the amount of work needed to spend on client code.
  • widely-used projects to maximize the potential user base.
  • open source, so that their implementation could be freely inspected, to simplify the implementation of compatibility.

Looking for long-established and widely-used open source RDBMS that are commonly known to serve as compatibility anchor for NewSQL databases, the search narrows down to just two: MySQL and PostgreSQL.

Why was compatibility with MySQL not the choice from the beginning?

Truth be told, as Ben Darnell recollected, MySQL was an appealing choice initially.

Google’s Spanner, developed with similar ideas as CockroachDB and with a similar audience in mind, aimed for some amount of MySQL compatibility. Other recent NewSQL RDBMSs, like MemSQL, opted for MySQL compatibility, too. Ben Darnell, like the rest of the early team at Cockroach Labs, even had more personal experience with MySQL than with PostgreSQL.

So what happened?

Initially, CockroachDB toyed with the idea of compatibility with MySQL. What tipped the balance in PostgreSQL’s favor was a combination of multiple factors.

There was initially a clear impression that PostgreSQL’s documentation of its network protocol was clearer, more detailed and overall more supportive of a third party implementation than MySQL’s documentation of its own protocol.

Meanwhile, the PostgreSQL License is compatible with CockroachDB’s own Apache License, which enables reuse of (some of) PostgreSQL’s own source code in CockroachDB unchanged. In contrast, MySQL (and its successor MariaDB) is released under the GNU GPL, which prevents direct reuse of MySQL code in CockroachDB.

Also, it became clear that MySQL had grown organically over time in a somewhat less principled manner than PostgreSQL. Throughout the documentation and source code, MySQL seemed to have more exceptions and special cases to care about. Proper SQL transactions came much later to MySQL than to PostgreSQL, and there remains significant cruft in the MySQL documentation and the MySQL ecosystem as a fallout of weak transaction isolation. As I understood the argument, the CockroachDB team did not like the perspective of sharing the same culture and ecosystem as one that usually only sees transaction isolation as a complicated, opt-in, “advanced” feature.

These factors alone caused CockroachDB to slowly but surely focus on PostgreSQL compatibility. But as time went on, some other aspects came up and confirmed this was a good choice. More on this below.

How compatible is CockroachDB with PostgreSQL?

Today, CockroachDB supports PostgreSQL’s network protocol, called “pgwire” in the CockroachDB source code, very well. It also supports most of PostgreSQL’s SQL syntax, by virtue of being able to reuse PostgreSQL’s syntax parser virtually as-is (with extensions). The compatibility story is however currently more murky at the level of the dialect’s semantics, simply because there is much more work to achieve adequate compatibility at that level.

Protocols for communication between things on a network are typically layered.

On the Internet, for example, the IP layer is at a lower level, TCP higher than IP (IP can function independently from TCP, and TCP is built upon it), and HTTP is higher than TCP (TCP can function independently from HTTP, and HTTP is built upon it).

For RDBMSs the communication is organized like this:

  • the SQL network protocol is at a similar abstraction level as TCP or HTTP on the Internet.
  • the SQL syntax is at one level above that.
  • the SQL dialect semantics is at one level even higher.

SQL RDBMSs do not typically explain their communication protocols like this in their docs, but application developers see this structure clearly in their code: when a driver can connect successfully to a database (the network protocol) there is still work to do, because they can still get errors if the app sends invalid SQL punctuation (the SQL syntax). Even when the punctuation is fine, there can still be errors when the app uses SQL functions not currently supported on the server (the SQL semantics). These practical stumbles during the development process of apps are the visible artifacts of a layered communication protocol.

What happened regarding compatibility with the PostgreSQL dialect? What are the plans?

Initially (back in 2015 and 2016), the idea was that CockroachDB would be compatible with PostgreSQL’s network protocol, so as to enable reuse of client drivers, but that it would provide its own, potentially PostgreSQL-incompatible SQL syntax and/or dialect semantics. In particular, it was envisioned that CockroachDB would provide sufficiently many specific SQL extensions that a custom SQL dialect would be necessary (or at least warranted).

And so early (non-released) versions of CockroachDB had a hybrid MySQL/Spanner/PostgreSQL dialect, available to clients over the PostgreSQL network protocol.

The assumption underlying this strategy was that users would want to reuse PostgreSQL drivers (which talk the network protocol) but would accept using CockroachDB-specific SQL queries with their drivers in exchange for CockroachDB-specific benefits.

As the team learned the hard way in the ramp-up to CockroachDB 1.0, many developers in the ecosystems that CockroachDB wants to enter *do not write their own SQL queries any more*—as opposed to, e.g., ten or twenty years ago.

By early 2016, it became clear CockroachDB did not have just client drivers to make compatible to stimulate adoption; it also had to make the higher level frameworks compatible. This in turn meant that the initial idea to restrict compatibility to the network protocol was insufficient, so the PostgreSQL compatibility mandate was extended throughout CockroachDB’s entire SQL layer. That, or invest engineering work to extend existing PostgreSQL frameworks to make them work with CockroachDB.

This is now well-understood and, in fact, both directions are being heavily invested in.

The priority is now to increase compatibility with PostgreSQL’s semantics out-of-the-box, for example by providing more and more of PostgreSQL’s built-in functions and operators, and by exposing more compatible data via the information_schema And pg_catalog introspection tables. This work is ongoing and future versions of CockroachDB aim to become increasingly more compatible in this way.

Meanwhile, there exist a few features where CockroachDB will likely never be fully compatible with PostgreSQL due to a fundamental difference in database architecture. For example, PostgreSQL’s FOR Locking clauses cannot be implemented efficiently in CockroachDB at all, because the concurrency control primitives in CockroachDB are so different. When existing client frameworks for PostgreSQL require such features, Cockroach Labs will instead invest into providing custom CockroachDB-specific versions of the framework, either by building them in-house or supporting third parties to do the work. As CockroachDB becomes more popular, the developers of the frameworks might even choose to implement CockroachDB-specific alternatives themselves.

In retrospect, was it the right choice?

As it turns out, making CockroachDB compatible with PostgreSQL is actually a lot of work. Would have it been any different if CockroachDB had chosen another route instead?

The first alternative, to provide a custom network protocol and SQL dialect, forcing the creation of a new application ecosystem from scratch, would not have been the right option. CockroachDB aims to create a huge community of users. Without compatibility with an established software ecosystem, there is a huge bootstrapping problem which the team had no experience in solving.

Furthermore, adopting compatibility has a huge benefit on the development process: it removes open questions from the design discussions. Open questions in the client/server interface of a networked software are a huge time sink and usually becomes source of costly disagreements between sub-teams or long-winded design iterations. By adopting compatibility with something, anything really, the CockroachDB team was able to utilize a definite source of answers for a large number of design decisions. This has accelerated the development by focusing efforts on more important matters, for example resilience and operational simplicity.

Another alternative route would have been to prioritize early compatibility with MySQL instead. The MySQL protocol and dialect, albeit less well documented and less principled as discussed above, is arguably simpler to implement—especially for the semantics aspects beyond the network protocol. MySQL has fewer SQL data types, fewer built-in functions, fewer introspection facilities, fewer configuration options. All this could have translated to less work for CockroachDB.

At this time, the CockroachDB team is still pretty comfortable with the choice of prioritizing PostgreSQL compatibility first. The arguments discussed above still hold, especially the code license and the programmer culture. In addition, over time, several other aspects in favor of PostgreSQL became clear.

For one, the acquisition of MySQL AB, the company behind MySQL, by Sun Microsystems (now Oracle) in 2008 has fragmented the MySQL ecosystem. MariaDB, while initially fully compatible, now provides its own feature set. There is no unified steering governance body behind MySQL’s future any more. PostgreSQL can be considered more future-proof in that regard. Also, Oracle now owns the bulk of MySQL’s intellectual property, and a company building a product too closely related to MySQL and appealing to a similar enterprise audience might land a bit too close to Oracle’s anti-competition radar for comfort.

However, the MySQL community is massive, and many are showing interest in porting applications to CockroachDB. For that reason, the CockroachDB team is actively developing MySQL migration tools, which are available in the latest alpha release.

Separately, PostgreSQL’s reference documentation is extremely clean, well-written, well-presented and developer-friendly, moreso than MySQL’s. It is an effective complement to CockroachDB’s own documentation, and users have reported that they are happy to use both together.

Finally, as years go by the specific compatibility choice ends up mattering less and less. By the time a project becomes well-known and enough users have adopted it in their tech stack, (social) network effects and the quality of provided support resources largely overshadow the initial ramp-up benefits of (tech) network or dialect compatibility. Hopefully, CockroachDB will find itself in this position soon enough.

So yes, in retrospect, probably still the right choice.





Copyright © 2018 Raphael ‘kena’ Poss. Permission is granted to distribute, reuse and modify this document according to the terms of the Creative Commons Attribution-ShareAlike 4.0 International License.

This work, “Why PostgreSQL in CockroachDB” by Raphael ‘kena’ Poss, is a derivative of “The PostgreSQL in CockroachDB - Why?” used under CC BY SA. To view a copy of this license, visit http://creativecommons.org/licenses/by-sa/4.0/.
